CV Mixer
Let's Go Shopping

CGS304 Plan

3D Model

The CGS304 arose out of a need for a small mixer that preserved the D.C. component of signals, at audio frequencies and below, specifically for the hobbyist synthesizer builder, though it's applications do not stop there. Its compact size means it can easily be included along with other circuit boards in modules that do not have enough inputs of their own, such as some VCAs or VCFs.

For mixing AC/Audio signals we recommend the CGS401.

PCB Dimensions: 1 " x 2" with 3.2mm fixing points 0.15" from the edges
Power Consumption:
+12V @
-12V @
